Description:

A direct replacement of the MS 880, the MS 881 is the most powerful chainsaw in the market with the highest displacement (121.6 cc) and engine power (6.4 kW). Built for high performance work, this saw is the optimum choice for professional foresters and loggers. Ideal for the most demanding forestry jobs, this chainsaw is excellent for working in extreme conditions when harvesting big timber. Chainsaw can be fitted to a saw frame. Fitted with a 2-MIX engine to comply with EU5 emission regulation and HD2 filter ensures long-service life. The MS 881 comes in 30, 36 and 41” bar lengths options with a .404” Rapid Super chain.

Specifications:

Engine and Performance:

• Displacement: 121.6 cm³
• Power Output: 6.4 kW / 8.6 bhp
• Maximum RPM: 11,000 RPM
• Speed at Maximum Power: 8,500 RPM
• Power-to-Weight Ratio: 1.5 kg/kW
• Cylinder: Chrome-plated
• Performance: 6.4 kW (8.6 hp)

Weight:

• System Weight: 12.57 / 13.23 / 14.24 kg (depending on configuration)
• Weight: 9.9 kg (without fuel, cutting attachment)

Chain and Sprocket:

• Chain Pitch/Type: .404" Rapid Super
• Sprocket (Number of Teeth): 7 Z
• Sprocket Type: Ring sprocket
• Chain Tensioning: Lateral chain tensioning
• Bumper Spike: 2 Steel claws

Sound and Vibration:

• Sound Pressure Level: 106 dB(A)
• Sound Power Level: 118 dB(A)
• Vibration (Left/Right): 8.9/8.9 m/s²

Fuel and Oil:

• Fuel Tank Volume: 1.30 L
• EPA Certified Fuel Consumption: 0.846 g/h or 0-3.205 L/h
• Oil Tank Volume: 700 cm³
• Oil Pump: Adjustable

Features:

• Anti-Vibration System: Standard AV-System
• Filter Type: HD2 filter
• Handle Type: Standard grip
• Filler Cap: Tool-free filler cap

Description

Features:

• Adjustable Automatic Oiler
• The Adjustable Automatic Oiler allows the user to adjust the lubricant of the guide bar and saw chain for different bar lengths and cutting conditions.
• Anti-Vibration System
• STIHL has developed a system for minimizing the vibration levels of handheld outdoor power equipment. The STIHL anti-vibration system helps reduce operator fatigue and provides a more comfortable working experience.
• STIHL ElastoStart™
• The ElastoStart™ starter handle is an exclusive feature of STIHL. It is a starting grip with a built-in shock absorber that helps reduce the effort when pulling on the starter cord. The ElastoStart™ starter grip noticeably reduces the sudden peak forces (compression) normally felt during cranking. The forces which occur at the grip after the first compression stroke are smoothed out.
• Fuel and oil caps with retainers
• The fuel and oil cap retainers keep the caps attached to the unit for added convenience.
• Side-Access Chain Tensioner
• The side-access chain tensioner makes it much more convenient for the user to adjust the saw chain with a bar wrench as opposed to the typical location of the guide bar adjustment screw.
• STIHL Quickstop®
• STIHL chainsaws are equipped with a chain stopping system designed to reduce the risk of injury in certain kickback situations. It is called a STIHL Quickstop® chain brake. The STIHL Quickstop® chain brake is designed to stop the rotation of the chain if activated by the operator’s hand or by inertia if the saw kicks back with sufficient force. In some working positions, the STIHL Quickstop® chain brake can be activated by inertia, stopping the chain within fractions of a second.
• Ematic™ Lubrication System
• The Ematic™ guide bar, when used with STIHL OILOMATIC® saw chain, will provide proper lubrication and less oil consumption than conventional methods. The system works because two ramps, strategically placed in the guide bar rail, help contain the flow of oil and direct all lubrication to the sliding faces of the bar and chain links as well as the rivets and driver holes, which in turn can reduce bar oil consumption up to 50%.
• Decompression Valve
• The decompression valve, also referred to as 'deco' or 'deco valve', vents compression in the cylinder for easier starting. The decompression valve temporarily reduces the compression in the combustion chamber during cranking and helps reduce the effort needed to pull the starter rope. It is opened manually and closes automatically as soon as the engine fires.
• HD2 Air Filter
• The new HD2 air filter on this unit is washable, providing extremely long filter life and lowering maintenance costs. The large surface area allows for longer run times between cleanings and high performance even while operating in dusty and dry conditions. Overall, the HD2 air filter provides better protection of the engine compared to standard air filters.
• The largest most powerful saw in the STIHL lineup
• With its updated engine design and up to 41” guide bar length, the MS 881 is the largest, most powerful chain saw in the STIHL lineup.
• Greater fuel efficiency and reduced exhaust emissions as compared to the previous model
• The MS 881 has the same power as the MS 880 while using less fuel and reducing exhaust emissions, saving time and money while also being better for the environment.
• Efficient stop switch technology
• Efficient stop switch technology saves users time and reduces the chance of flooding the engine when starting.
• Easy manual adjustment of the carburetor settings
• The simplified design of the carburetor allows for easy manual adjustment.

 Specifications:

Engine and Power:

• Power Source: Gasoline
• Engine Power: 8.6 bhp
• Displacement: 7.42 cu. in. (121.6 cc)

Weight and Size:

• Powerhead Weight: 21.8 lbs. (without fuel, bar, or chain)
• Recommended Guide Bar Length: 25 in. (other bar sizes available)

Chain and Bar:

• Chain Type: 3/8" RS3 (Oilomatic® Chain)
• Guide Bar Length (Recommended): 25 in.

Fuel and Oil:

• Fuel Capacity: 44 oz.
• Chain Oil Capacity: 23.7 oz.

DESCRIPTION

The largest and most powerful chainsaw in the STIHL lineup

For the largest, toughest and most demanding jobs, professionals can find the performance they need in the MS 881 chainsaw. With its updated engine design and up to 41” guide bar length, the MS 881R is the largest, most powerful saw in the STIHL lineup. Greater fuel efficiency than the previous model means savings of time and money. Another time-saving feature is the stop switch, which automatically returns to run position after the engine is stopped, reducing the chance of flooding the engine when starting.

FEATURES

• Ematic™ Lubrication System: The Ematic™ guide bar, when used with STIHL OILOMATIC® saw chain, will provide proper lubrication and less oil consumption than conventional methods. The system works because two ramps, strategically placed in the guide bar rail, help contain the flow of oil and direct all lubrication to the sliding faces of the bar and chain links as well as the rivets and driver holes, which in turn can reduce bar oil consumption up to 50%.
• HD2 Air Filter: The HD2 air filter on this unit is washable, providing extremely long filter life and lowering maintenance costs. The large surface area allows for longer run times between cleanings and high performance even while operating in dusty and dry conditions. Overall, the HD2 air filter provides better protection of the engine compared to standard air filters.
• STIHL Quickstop®: STIHL chainsaws are equipped with a chain stopping system designed to reduce the risk of injury in certain kickback situations. It is called a STIHL Quick stop® chain brake. The STIHL Quick stop® chain brake is designed to stop the rotation of the chain if activated by the operator’s hand or by inertia if the saw kicks back with sufficient force. In some working positions, the STIHL Quick stop® chain brake can be activated by inertia, stopping the chain within fractions of a second.
• Side-Access Chain Tensioner: The side-access chain tensioner makes it much more convenient for the user to adjust the saw chain with a bar wrench as opposed to the typical location of the guide bar adjustment screw.
• Fuel and oil caps with retainers: The fuel and oil cap retainers keep the caps attached to the unit for added convenience.
• Anti-Vibration System: STIHL has developed a system for minimizing the vibration levels of handheld outdoor power equipment. The STIHL anti-vibration system helps reduce operator fatigue and provides a more comfortable working experience.
• STIHL Elasto Start™: The Elasto Start™ starter handle is an exclusive feature of STIHL. It is a starting grip with a built-in shock absorber that helps reduce the effort when pulling on the starter cord. The Elasto Start™ starter grip noticeably reduces the sudden peak forces (compression) normally felt during cranking. The forces which occur at the grip after the first compression stroke are smoothed out.
• The largest, most powerful saw in the STIHL lineup: With its updated engine design and up to 41” guide bar length, the MS 881 is the largest, most powerful chainsaw in the STIHL lineup.
• Greater fuel efficiency and reduced exhaust emissions as compared to the previous model: The MS 881 has the same power as the MS 880 while using less fuel and reducing exhaust emissions, saving time and money while also being better for the environment.
• Efficient stop switch technology: Efficient stop switch technology saves users time and reduces the chance of flooding the engine when starting.
• Decompression Valve: The decompression valve, also referred to as 'deco' or 'deco valve', vents compression in the cylinder for easier starting. The decompression valve temporarily reduces the compression in the combustion chamber during cranking and helps reduce the effort needed to pull the starter rope. It is opened manually and closes automatically as soon as the engine fires.
• Adjustable Automatic Oiler: The Adjustable Automatic Oiler allows the user to adjust the lubricant of the guide bar and saw chain for different bar lengths and cutting conditions.
• Easy manual adjustment of the carburetor settings: The simplified design of the carburetor allows for easy manual adjustment.

SPECIFICATIONS

• Power Source: Gas
• Powerhead Weight: 21.8 lbs.
• Guide Bar Length (Recommended): 25 in.
• Oilomatic® Chain: 3/8" RS3
• Chain Oil Capacity: 23.7 oz.
• Engine Power: 8.6 bhp
• Fuel Capacity: 44 oz.
• Displacement: 121.6 cc

NOTES:

STIHL recommends #3946 (46 RS 80) OILOMATIC® saw chain and 25” 3002 000 9731 Ematic™ guide bar combination. Compatible guide bar ranges: 21" to 41" Warnings and Safety IMPORTANT SAFETY INFORMATION The occurrence called “kickback” can cause serious or fatal injury. Always read the instruction manual carefully before using your saw. STIHL uses a green and yellow color-coding system to help you select a powerhead, bar and chain combination that complies with the kickback requirements of ANSI Standard B175.1 (gasoline-powered saws) and §30 of UL 1662/ ANSI Standard B175.1 (electric chainsaws). Ask your STIHL dealer about safe operating procedures and the advantages of the STIHL Quickstop® chain brake, STIHL Quickstop® Plus additional chain braking feature, STIHL reduced kickback bars and STIHL low-kickback saw chains. STIHL recommends the use of green reduced kickback bars and green low kickback chains on all STIHL chainsaws. Note: STIHL recommends use of fuel with no more than 10% Ethanol content. Using fuel with greater than 10% Ethanol content may cause damage to your equipment and may void your STIHL warranty. * The actual listed guide bar length can vary from the effective cutting length based on which powerhead it is installed on. WARNING! Improper use of any power tool may cause serious or fatal injury. Read, understand and follow carefully the operating and safety instructions in your instruction manual before using such products. STIHL products sold through U.S. STIHL Dealers are for distribution in the United States only.
