Description:

Features:

• Commercial-grade 25.5 hp Kawasaki® FX801V (852cc) engine
• A fully fabricated 54-inch 10-gauge steel commercial deck shell with top bottom and side reinforcements plus standard 24" tires give you more ground clearance to easily hop on curbs.
• A large, fully adjustable suspension platform allows you to adjust tension and glide comfortably through tough terrains.
• High-performance commercial Hydro-Gear® PK 12cc pumps & Parker® TL 240cc wheel motors deliver quick response to the drive wheels and smooth control for cutting speeds up to 10 mph.
• 3-year limited commercial warranty (no hour limitations) and 5-year/1,750-hour limited deck assembly warranty.

Specifications:

Engine

• Brand: Kawasaki®
• Model: FX Series, Model Number 801V
• Displacement: 852cc
• Output: 25.5 HP
• Starter Type: Electronic
• Fuel Tank Capacity: 7.5 gal. US (28.4 L)
• Cylinders: Twin
• Start Type: Ignition Key
• Oil Capacity: 2.0 qt. US (1.89 L)
• Lubrication: Fully pressurized
• Charging System: 15 amp regulated
• Fuel Gauge: Not included
• Choke: Separate Choke
• Air Filter: High Density
• Oil Filter: Yes
• Fuel Delivery: Carburetor

Drive System

• Transmission: 12cc Hydro-Gear® pumps / 240cc Parker® wheel motors
• Forward Speed: 10 mph (16 km/h)
• Reverse Speed: 5 mph (8 km/h)

Cutting Deck

• Width: 54 in
• Material: 10-gauge steel
• Engagement (PTO): Electronic with quick reset
• Construction: 10-gauge shell with 7-gauge top & bottom reinforcement
• Spindle Construction: Heavy-duty 8" aluminum housing, 35mm double-row sealed ball bearings, 1-3/8" through-shaft, maintenance-free
• Blades: Three 19" high-lift Marbain blades, 1-1/2" overlap
• Deck Lift: Hand lever adjusting spring lift with pin selector for height
• Cutting Height Range: 1.5" - 4.5"
• Anti-Scalping: 2 front deck gauge wheels

Chassis

• Frame: 2" x 3" full-length tube frame
• Front Axle: 2" x 3" tube construction
• Front Caster Mount: 3/8" thick steel
• Suspension: Hand lever adjust, 3-position spring suspension foot platform

Controls

• Brakes: Hand lever control / external band
• Steering: Lap Bar Steering Wheel Control

Wheels

• Rear Tires: 24"x12"-12"
• Front Tires: 13x5-6" Reliance Run Flat Carlisle

Dimensions

• Length/Width/Height: 69" / 68" / 56"
• Weight (approx.): 1080 lbs

Additional Specifications

• Hour Meter: Crew Boss
• Model Number: 53AI8CSA050
• Residential Warranty: 3-year / no-hour-limit
• Deck Shell Warranty: 5-year / 1,750-hour limited manufacturer’s warranty
