Description:
Take productivity and comfort up a notch. The ISX™ 2200 boasts our most advanced suspension technology – ForeFront™ Suspension, ensuring operator comfort. A 2-belt iCD™ cutting system delivers unrivaled cut quality and the heavy-duty Hydro-Gear® ZT-4400™ Transaxle drive system provides power and durability to get the job done.
Features:
NEW! iCD™+ Cutting System:
- Redesigned for enhanced performance, increased durability, and superior results. Available on select models.
NEW! USB Port:
- Features 12V-60V, USB Type A & C ports located on the dash panel for easy access and charging.
ForeFront™ Suspension System:
- Utilizes four upper and lower control rods and mower-specific shocks to ensure the front caster bearing remains vertical through the full range of travel. Results in a smoother ride, more precise tracing of the terrain, and an improved cut.
Vanguard BIG BLOCK™ Engine:
- EFI-ETC engine with Oil Guard technology delivers a 500-hour oil change interval and 28 hp*, providing added cutting performance to excel in thick, dense, and wet conditions. Available on select models.
Premium Suspension Seat:
- Select models feature a premium high-back suspension seat with armrests, adjustable lumbar, back recline, and headrest (ISX3300 model).
Hydro-Gear ZT-4400™ Transaxles:
- Dual-commercial transaxles with 8.3" cooling fans to repel debris.
Adjustable Cut Height:
- Foot-operated deck lift, with adjustable pedal, can change cut height in 1/4" increments from 1.5"- 5".
Ride-On Mower Warranties:
- Coil-Over-Shocks and all suspension-related components are covered for 5 years (60 months), for unlimited hours, demonstrating a commitment to performance, productivity, and durability.
Specification:
Engine:
- Brand: Vanguard™ 810cc EFI with Oil Guard
- Power Rating: 28
- Displacement (cc): 810
- PTO: Electric
- Cylinders: 2
- Starter: Electric
- Fuel Type: Gasoline
- Fuel Tank Capacity (gal): 11
- Hour Meter/Instrumentation: Dual-function hour meter, fuel level gauge in each tank
Deck:
- Size (in): 60
- Cutting Height (in): 1.5 - 5
- Spindles: Cast-iron greaseable
- Deck Construction: iCD™+ Cutting System, 2-Belt
Suspension:
- Suspension: ForeFront™ Suspension System
Transmission:
- Transmission: Dual, commercial Hydro-Gear® ZT-4400™ Transaxles with 8.3" cooling fans
Dimensions and Weight:
- Drive Axles (in): 1.375
- Caster Tires (in): 13 x 6.5-6
- Drive Tires (in): 24 x 12-12
- Ground Speed-Fwd (mph): 0-10
- Ground Speed-Rev (mph): 0-5
- Overall Length (in): 82.5
- Overall Width (in) Deflector Down/Deflector Up: 74 / 65
- Dry Weight (lbs): 1405
Seat Package:
- Premium high-back Suspension Seat with adjustable armrests, adjustable lumbar, and back recline.
Certified Roll-over Protection System:
- 180° foldable
Controls / Safety Group:
- Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controls
Parking Brake / Safety Circuit:
- Hand-operated Internal transaxle brake
Warranty:
- Engine: 3-Year limited manufacturer's warranty
- Balance of Machine: 4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over shocks and all suspension-related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see the operator's manual for complete details.
Engine Configuration:
- Vanguard™
Width | Weight | Height | Length |
---|---|---|---|
0 Inch | 1405 Pounds | 0 Inch | 82.5 Inch |
