Description:

Engineered to tame even the most demanding environments, you'll find the Ferris® F210Z is up to the challenge. Equipped with premium components, like dual commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles and cast-iron spindles with top access grease fittings, this is one workhorse you and your crew can depend on. Choose between multiple engine options: a Vanguard™ 810 and Vanguard™ 810 EFI offering a 500 hour oil change interval with the new Oil Guard System or a Kawasaki® FX801V, all with a 3-year limited manufacturer's warranty†

Features:

• 500 Hour Oil Change (Select Models): Vanguard™ Engines with Oil Guard System reduce maintenance time and costs by up to 60%.**
• Affordable Power: Now available with a Briggs & Stratton® Vanguard™ 810cc engine, which delivers uncompromised power at an affordable price.
• iCD™ Cutting System: The iCD™ Cutting System was engineered to produce the best possible cut in a multitude of conditions.
• Accessibility: Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service.
• Cast-Iron Spindles: Longer usable life, 1" shaft with top access grease fitting for greaseable dual ball bearings, six-bolt 8" flange design adds strength and greater dispersal of energy to deck assembly.
• Foot-Operated Deck Lift: With an adjustable pedal, easily change change cut height in 1/4" increments from 1.5"- 6".
• Commercial Transmission: Dual, commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles deliver unmatched power and durability.
• Premium Seat: Mid-back suspension seat with adjustable arm rests that helps take the bumps out of your work day.
• Ride-On Mower Warranties†: 4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Belts, tires, brake pads, battery, blades: 90 days.
• Traction: Large 24" drive tires allow for greater traction, smoother ride and improved curb climbing performance.

Specifications

• Engine Brand: Kawasaki® FX801V
• Displacement (cc): 852
• Cylinders: 2
• Fuel Tank Capacity (gal): 11
• Cutting Height (in): 1.5 - 6
• Deck Construction: iCD™ Cutting System
• Transmission: Dual commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles with 9" cooling fans
• Caster Tires (in): 13 x 6.5-6 Flat-free
• Ground Speed-Fwd (mph): 0-10
• Overall Length (in): 79
• Dry Weight (lbs): 1190
• Instrumentation/Hour Meter: Fuel level gauge in each tank, hour meter
• Controls / Safety Group: Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls
• Warranty (Engine) †: 3-Year limited manufacturer's warranty
• Brake: Internal transaxles
• Warranty Consumer Engine Info: 3-Year limited manufacturer's warranty
• Engine Power Rating *: 25.5 gross hp
• PTO: Electric
• Starter: Electric
• Cutting Width (in): 61
• Spindles: Cast-Iron
• Suspension: N/A
• Drive Axles (in): 1.375 Tapered
• Drive Tires (in): 24 x 12-12
• Ground Speed-Rev (mph): 0-5
• Overall Width (in) Deflector Down/Deflector Up: 76 / 63
• Seat Package: Premium suspension mid-back seat with arm rests, adjustable fore and aft positioning
• Certified Roll-over Protection System: Standard, 165° foldable
• Parking Brake / Safety Circuit: Internal transaxle
• Warranty (Balance of Machine) †: 4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coverage on other components varies, please see operator's manual for complete details.
• Engine Manufacturer: Kawasaki®
• Horse Power: 25.5 hp
• Engine Type: FX801V
• Displacement: 852 cc

General Specifications

• Transmission: Dual commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles with 9 in. cooling fans
• Wheel Size: 24 x 12-12 in.
• Fuel Capacity: 11 gal.

Deck Specifications

• Deck Size: 61 in.

Description:

The Leader In Suspension Technology For Turf

Featuring the next generation of Ferris suspension technology - ForeFront™ Suspension, a 2-belt iCD™ cutting system, heavy-duty dual commercial Hydro-Gear® ZT-5400 drive system and travel speeds up to 12 mph, the ISX™ 3300 is engineered to increase efficiency and operator comfort.

Features

• Forefront™ Suspension System
• Ride-On Mower Warranties
• Redesigned Rear Bumper
• 500 Hour Oil Change
• Drive System: Dual, commercial Hydro-Gear® ZT-5400 Powertrain® transaxles with 9" cooling fans
• Premium High-Back Suspension Seat
• Adjustable Cut Height
• Hercules™ II Cast-Iron: Hercules™ II Cast-Iron; 10" dia. cast-iron with industrial double row angular contact ball bearing with 1 3/16" dia. shaft. Contact ball bearings with 1 3/16" dia. shaft.

Specifications

• Model Number: 5901982
• Engine Brand: Kawasaki® FX1000V EFI
• Engine Power Rating *: 38.5
• Displacement (cc): 999
• Cylinders: 2
• Starter: Electric
• Fuel Type: Gasoline
• Fuel Tank Capacity (gal): 11
• Hour Meter/Instrumentation: Dual-function hour meter, fuel level gauge in each tank
• Cutting Width (in): 61
• Cutting Height (in): 1.5 - 5
• Spindles: Hercules™ II Cast-Iron
• Deck Construction: iCD™ Cutting System
• Suspension: ForeFront™ Suspension System
• Transmission: Dual commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles with 9" cooling fans
• Drive Axles (in): 1.375
• Caster Tires (in): 13 x 6.5-6
• Drive Tires (in): 26 x 12-12
• Ground Speed-Fwd (mph): 0-12
• Ground Speed-Rev (mph): 0-5
• Overall Length (in): 84.5
• Overall Width (in) Deflector Down/Deflector Up: 77/66.5
• Dry Weight (lbs): 1470
• Seat Package: Premium high-back Suspension Seat with arm rests, multiposition head rest, adjustable lumbar and back recline
• Certified Roll-over Protection System: 165° foldable
• Controls / Safety Group: Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls
• Parking Brake / Safety Circuit: Hand operated internal transaxle brake
• Warranty (Engine) †: 3-Year limited manufacturer's warranty
• Warranty (Balance of Machine) †: 4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Belts, tires, brake pads, battery, blades: 90 days.
• Engine Configuration: Kawasaki®

Specification:

Engine:

• Manufacturer: Kawasaki®
• Horse Power: 38.5 hp
• Type: FX1000V EFI
• Displacement: 999cc

General:

• Transmission: Dual commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles with 9 in. cooling fans
• Wheel Size: 26 x 12-12 in.
• Fuel Capacity: 11 gal.

Deck:

• Deck Size: 61 in.

Description:

The SRS™ Z1 offers all of the same great productivity and comfort as the larger SRS Z2, but in a more compact package. With smaller mowing deck options, the Z1 is optimal for navigating through tight gates or loading on smaller trailers. True to the Soft Ride Stand-on (SRS) series, the adjustable operator platform on the Z1 features suspension technology, improving operator comfort and performance.

Features

• Ride-On Mower Warranties†: Coil-Over-Shocks and all suspension-related components are covered for 5 years (60 months), for unlimited hours. We are committed to providing performance, productivity and durability.
• Speed Control Setting: The easy locking 3-position speed control setting is conveniently located and requires no tools to facilitate smooth operation in a wide range of conditions.
• Suspension Platform System: The suspension platform system is adjustable for a large range of weights and operating conditions, optimizing operator comfort and increasing productivity.
• Standing Comfort: Ergonomically designed thigh pad provides superior operator comfort and stability, especially on hilly terrain.
• Adjustable Height of Cut: Height of cut is easily changed from the operator compartment for no hassle curb climbing and trailer loading. The hand-operated deck lift can change cut height in 1/4" increments from 1.75"- 4.5".
• Integrated Mowing Transmissions: Commercial Hydro-Gear® ZT-3400® transaxles with 7" cooling fans are designed for high performance and are fully serviceable.
• iCD™ Cutting System: Innovative iCD™ Cutting System was engineered to produce the best possible cut in a multitude of conditions.
• Generous Fuel Capacity: A 6-gallon fuel tank is centrally located for consistent balance, and the fuel filler neck is conveniently located on the side for easy filling.

Specifications

• Model Number: 5901546
• Engine Brand: Kawasaki® FX600V
• Engine Power Rating (hp) *: 19
• Starter: Electric
• Displacement (cc): 603
• PTO: Electric
• Cylinders: 2
• Fuel Tank Capacity (gal): 6
• Cutting Width (in): 36
• Cutting Height (in): 1.75-4.5
• Spindles: Aluminum
• Suspension: Adjustable coil-over-shock, Operator Suspension Platform
• Transmission: Hydro-Gear® ZT-3400® transaxles with 7" cooling fans
• Drive Axles (in): 1.125
• Drive Tires (in): 23 x 8.5-12
• Caster Tires (in): 11 x 4-5, Flat free
• Ground Speed-Fwd (mph): 0-8
• Ground Speed-Rev (mph): 0-4
• Overall Length (in): 63.75
• Overall Width (in) Deflector Down/Deflector Up: 49 / 42
• Dry Weight (lbs): 813
• Seat Package: N/A
• Certified Roll-over Protection System: N/A
• Instrumentation: Dual-function hour meter, fuel level gauge
• Safety Group/Controls: Operator presence in platform, parking brake safety circuit for starting engine, automatic PTO restart
• Parking Brake / Safety Circuit: Hand-operated internal transaxle brake
• Warranty (Balance of Machine) †: 4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 6 years (60 months) unlimited hours. Transaxles are covered for 3 years (36 months). Coverage on other components varies, please see operator's manual for complete details.
• Warranty (Engine) †: 3-Year limited manufacturer's warranty

DESCRIPTION

Affordable Commercial Zero Turn With Next Generation Ferris Suspension Technology

Featuring the next generation of Ferris® suspension technology - ForeFront™ Suspension, a two-belt iCD™ cutting system, heavy-duty Hydro-Gear® ZT-3400® drive system and travel speeds up to 10 mph, the ISX™ 800 is engineered to increase efficiency and operator comfort.

FEATURES

• ForeFront™ Suspension System: The system utilizes four upper and lower control rods that ensure the front caster bearing remains vertical through the full range of travel. This controlled motion results in a smoother ride, more precise tracing of the terrain and an improved cut.
• Ride-On Mower Warranties
• Easy Access: Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service.
• Integrated Transmission: Commercial Hydro-Gear® ZT-3400™ transaxles, with 7" cooling fans, are designed for high performance and are fully serviceable.
• iCD™ Cutting System: iCD™ Cutting System was engineered to produce the best possible cut in a multitude of conditions. The ISX™ 800 is equipped with a 2-belt deck and provides a 3-year belt limited warranty (See operator's manual for complete warranty details).
• Mower Spindles: Cast-aluminum greaseable spindles feature 1" shaft with 2.5" x 1" dual ball bearings with top access grease fittings and pressure relief valve.
• Acres per Hour: Mows up to 5 acres per hour, based on 80% efficiency.
• Miles per Hour: Up to 10 MPH ground speed, reverse 5 MPH.

SPECIFICATIONS

• Model Number: 5902022/5902001
• Engine Brand: Kawasaki® FT730V - EFI
• Engine Power Rating *: 26
• Displacement (cc): 726
• PTO: Electric
• Cylinders: 2
• Starter: Electric
• Fuel Type: Gasoline
• Fuel Tank Capacity (gal): 5.5
• Hour Meter/Instrumentation: Dual-function hour meter, fuel level gauge in tank
• Cutting Width (in): 61
• Cutting Height (in): 1.5 - 5
• Spindles: Aluminum Greaseable
• Deck Construction: iCD™ Cutting System, 2-Belt
• Suspension: ForeFront™ Suspension System
• Transmission: Dual commercial Hydro-Gear® ZT-3400® transaxles with 7" cooling fans
• Drive Axles (in): 1.125
• Caster Tires (in): 13 x 6.5-6
• Drive Tires (in): 23 x 10.5-12
• Ground Speed-Fwd (mph): 0-10
• Ground Speed-Rev (mph): 0-5
• Overall Length (in): 83
• Overall Width (in) Deflector Down/Deflector Up: 75 / 63.5
• Dry Weight (lbs): 1197
• Seat Package: Mid-back suspension seat with arm rests
• Certified Roll-over Protection System: 180° foldable
• Controls / Safety Group: Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controls.
• Parking Brake / Safety Circuit: Hand operated Internal transaxle brake
• Warranty (Engine) †: 3-Year limited manufacturer's warranty
• Warranty (Balance of Machine) †: 4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator's manual for complete details.
• Engine Configuration: Kawasaki®

Description:

The Cub Cadet® Ultima Series ZTX6 60 60-in. 25.5 HP* Zero-Turn Lawn Mower with AeroForce™ Max Reinforced Fabricated Deck is designed to deliver a premium cut with few clumps and stragglers, fine clippings and evenness. Features 10-gauge reinforced fabricated steel with low maintenance spindles, smooth arc triple-blades, cut overlap and deep dome deck design allowing you to mow a wide area of grass. Dual hydrostatic transmissions engineered for quick ground speeds that leaves your yard with a professional-quality finish.

Features:

• A high-strength 1.5 in. x 3 in. tubular steel frame is built to provide optimal strength and rigidity while allowing accessibility for easy routine maintenance
• Commercial grade 852cc/25.5HP* Kawasaki® FX801 V-Twin OHV engine designed for reliable starting and exceptionally smooth, quiet operation.
• Commercial grade dual hydrostatic rear-wheel transmissions for quick up to 9 MPH forward (3.5 MPH reverse) zero-turn controlled ground speeds.
• Zero-Turn Mower

Specification:

Engine:

• Brand: Kawasaki®
• Model: FX Series 801V
• Displacement: 852cc
• Output: 25.5HP
• Starter Type: Electric
• Fuel Tank Capacity: 5.5 gal. US (20.82 L)
• Cylinders: Twin
• Start Method: Ignition Key
• Oil Capacity: 2.1 qt US (2 L)
• Lubrication: Fully pressurized
• Charging System: 15 amp regulated
• Fuel Gauge: Yes
• Governor: Mechanical
• Choke: Separate Choke
• Air Filter: Single element
• Oil Filter: Yes
• Fuel Delivery: Carburetor
• Battery:
• Type: AGM (Absorbent Glass Mat)
• Voltage: 12V
• CCA: 210

Drive System:

• Transmission: Hydro-Gear ZT 3400 Charged
• Forward Speed: 9 MPH / 14.5 km/h
• Reverse Speed: 3.5 MPH / 5.6 km/h
• Drive Type: Hydrostatic

Cutting Deck:

• Width: 60 inches
• Engagement: Electric PTO
• Material: 10-gauge steel with 2-gauge reinforcement
• Construction: Fabricated
• Blades: Three
• Deck Lift: Foot pedal with Dial Adjust
• Cutting Heights: 1" - 4.75"
• Anti-Scalping: Three gauge wheels
• Positions: 17

Chassis:

• Frame: 1.5" x 3" tubular steel
• Turning Radius: 0°
• ROPS: Yes (Roll Over Protection System)
• Tow Hitch: Yes
• Corrosion Protection: Yes

Controls:

• Cruise Control: No
• Brakes: Disc
• Steering Control: Lap Bars

Comfort:

• Seat Type: 24" high back with Armrests
• Seat Adjustment: Lever
• Front Caster Suspension: Yes

Wheels:

• Rear Tires: 24"x 12"-12"
• Front Tires: 13"x 6.5"-6"
• Tread: Turf Master / Multi Trac

Specifications:

• Series: Ultima Series™ ZTX
• Additional Features: Hour Meter, Mulch Kit available separately, Dual-LED Headlights, Cup Holder, Operator Presence System, Integrated Lap Bar Parking Brake

Warranty:

• Residential Warranty: 4-year or 800 hours
• Frame Warranty: Lifetime Limited
• Deck Shell Warranty: Lifetime Limited
• Commercial Warranty: 4-year or 800 hours

Model Number: 47TIAHA8A10

Description

The Cub Cadet ZT1 42 FAB is a powerful and efficient zero-turn mower that delivers exceptional performance and precision cutting. Its main features include a 42-inch fabricated deck made of heavy-duty steel that provides superior cutting quality, as well as a powerful 18 HP/726cc Kawasaki FR691 twin-cylinder OHV engine delivers high-performance power to tackle your yard The ZT1 42 FAB also features a comfortable high-back seat, dual hydrostatic transmissions, and a smooth and easy-to-operate lap bar steering system. With its high-quality construction, advanced features, and impressive performance, this mower can make mowing your lawn a breeze, saving you time and effort while achieving a perfectly manicured lawn.

Product Highlights

• A 18 HP/726cc Kawasaki FR691 twin-cylinder OHV engine delivers high-performance power to tackle your yard
• Dual hydrostatic transmissions allow for quick and effortless 7 MPH forward (3.5 MPH reverse) ground speeds that leaves your lawn with a professional-quality finish
• A continuous square 2 in. x 2 in. tubular steel frame with fully e-coat lower frame and triple guard corrosion defense system, a multi-step process that electronically applies automotive-grade corrosion resistance with meticulous care to protect against wear and tear
• 42-in. AeroForce fabricated deck that delivers a signature cut with fewer clumps and stragglers, finer clippings and increased evenness.

Product Specifications

Engine

• Engine Brand: Kawasaki®
• Engine Model: FR Series
• Engine Model Number: 600V
• Engine Displacement: 726cc
• Engine Output: 18HP
• Starter Type: Electric
• Fuel Tank Capacity: 3.5 gal. US (13.25 L)
• Cylinders: Twin
• Engine Start: Ignition Key
• Engine Oil Capacity: 1.8 qts. US (1.7 L)
• Lubrication: Fully pressurized
• Charging System: 12 amp regulated
• Fuel Gauge: No
• Governor: Mechanical
• Choke: Separate Choke
• Air Filter: Dual element
• Oil Filter: Yes
• Fuel Delivery: Carburetor

Battery

• Battery: 210 CCA
• Battery Type: AGM (Absorbent Glass Mat)
• Battery Voltage: 12V

Drive System

• Transmission: Hydro-Gear EZT 2200
• Forward Speed: 7 MPH / 11.3 km/h
• Reverse Speed: 3.5 MPH / 5.6 km/h
• Drive System: Hydrostatic

Cutting Deck

• Deck Cutting Width: 42 in
• Deck Wash: No
• Deck Material: 11-gauge steel
• Deck Engagement (PTO): Electric
• Deck Construction: Fabricated
• Blade(s): Two
• Deck Lift: Foot pedal with Dial Adjust
• Cutting Height Range: 1'' - 4.5''
• Anti-Scalping: Two gauge wheels
• Deck Positions: 15

Warranty

• Warranty: 3-year unlimited hours
• Frame Warranty: Lifetime Limited
• Deck Shell Warranty: Lifetime Limited
• Commercial Warranty: No

Chassis

• Frame: 2'' x 2'' tubular steel
• Turning Radius: 0°
• ROPS: No
• Rear Tow Hitch: Yes
• Corrosion Protection: Yes

Controls

• Cruise Control: No
• Brakes: Disc
• Steering Control: Lap Bars

Comfort

• Seat Type: 20" high back
• Armrest: sNo
• Seat Adjustment: Knob

Wheels

• Rear Tires: 20”x 8”-8"
• Front Tires: 11"x 6"-5"
• Tire Tread: Turf Master / Multi Trac

Additional Specifications

• Hour Meter: No
• Mulch Kit: Available separately
• Headlight(s): Dual-LED
• Cup Holder: Yes
• Operator Presence System: Yes
• Parking Brake: Lap Bar Integrated
• Model Number: 17RIEACE010

Specifications

• Series: Ultima Series™ ZT

Disclaimers

• Specifications: Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
